IW5 Plunger — Precision Pump Element Rau Siab -Performance Diesel Systems

Me me geometry. Cov nyhuv loj. CovIW 5 plungeryog ib tug precision-engineered hydraulic caij uas txiav txim siab npaum li cas cov roj twj tso kua mis diesel nyob rau hauv siab heev. Tsis zoo li qhov pom ntawm lub cav, IW5 ua haujlwm hauv lub twj tso kua mis qhov twg micron - theem kam rau siab txiav txim siab rau -stroke ntim, lub sij hawm nce siab thiab ntev - lub sij hawm noj qab haus huv ntawm cov tshuaj txhaj tshuaj thiab tom qab kho tshuab. Thaum raug teev thiab teeb tsa, IW5 plunger tuaj yeem rov ua kom muaj zog thiab txuas ntxiv cov kev pabcuam tsis tau hloov tag nrho lub twj tso kua mis.





Lub IW5 yog tsim los rau cov tsev neeg twj tso kua mis uas xav tau ultra- ntim khoom sib npaug - feem ntau pom nyob rau hauv nruab nrab- thiab hnyav- daim ntawv thov lub luag haujlwm. Cov yam ntxwv tseem ceeb ntawm engineering muaj xws li:

Micro- tiav sealing nto:iav-lapped tiav rau qhov tsawg kawg nkaus micro- leakage thiab tsis tshua muaj kev sib txhuam.

Optimized metallurgy:alloy steels xaiv rau txheej txheej tawv tawv (nitrided lossis induction-hardened) thiab cov tub ntxhais tawv tawv kom tiv taus qaug zog.

Tight dimensional bands:concentricity thiab txoj kab uas hla tolerances nyob rau hauv tsawg microns; muaj nyob rau hauv cov chav kawm txoj kab uas hla rau kev sib tw -pab pawg.

Anti-cavitation geometry:contoured profiles uas txo vapor pocketing thiab yaig nyob rau hauv siab - siab mus.

Cov yam ntxwv no txo ​​qis cov qhab nia thiab ua kom ruaj khov xa roj thoob ntau txhiab teev.





IW5 plungers feem ntau yog stocked rau cov tsev neeg twj siv nyob rau hauv kev lag luam tsheb thauj khoom, siv cov khoom siv, marine auxiliaries thiab industrial generators. Vim hais tias plunger haum yog lub twj tso kua mis- tshwj xeeb, ib txwm phim lub plunger code lossis twj tso kua mis serial / tag ua ntej xaj. Qhov sib txawv me me ntawm qhov sib txawv tseem ceeb - qhov pom kev zoo sib xws tsis yog kev kuaj xyuas kom haum.





• Kev nrawm dua, txhim khu kev qha txias pib vim qhov kev kwv yees kev tsheb ciav hlau siab tsim.
• Txo cov pa luam yeeb dub thiab txhim kho combustion efficiency, txo DPF / SCR load.
• Tsawg qhov tshwm sim ntawm injector chatter thiab lub tog raj kheej tsis txaus.
• Txuas lub twj tso kua mis lub neej thiab tsawg dua kev kho dua ntxov ntxov thaum ua ke nrog kev pom zoo.

Hauv luv luv: hloov IW5 plungers hnav yog qhov siab -ROI kho thaum lub twj tso kua mis vaj tse nyob hauv qhov kev txwv.





Tshawb xyuas & ntsuas qhov bore- xyuas qhov sib npaug, taper thiab phau ntawv hnav. Yog hais tias lub bore tau qhab nia los yog oval tshaj qhov txwv, machining lossis hloov cov tub ntxhais yuav tsum tau ua.

Kev huv huv yog qhov yuav tsum tau ua- sib sau ua ke nyob rau hauv lub laminar ntws lub rooj ntev zaum los yog particle- tswj cheeb tsam; microscopic khib nyiab ruins tshiab plungers.

Muab cov chav kawm sib tw- thaum ua haujlwm ntau-plunger twj tso kua mis, txheeb plungers los ntawm chav kawm thiab nruab raws li cov khoom sib txuam kom ua kom muaj qhov sib npaug.

Hloov cov khoom siv- ib txwm haum cov nplhaib sealing tshiab, cov springs thiab inlet screens thaum kho dua tshiab.

Lub rooj zaum -validate- Kev ntsuas siab tsim, xau thiab ntws ntsuas ntawm lub rooj zaum calibrated tsis yog -xav tau. Sau thiab txuas cov ntawv ntws rau kev taug qab.

Ua raws li cov haujlwm no ua rau txo qis rov qab los thiab tiv thaiv cov dej hauv qab.





Txoj kev tsheb nqaj hlau qeeb qeeb (ntev cranking), tshwj xeeb tshaj yog nyob rau hauv txias txias.

Lub tog raj kheej tsis sib npaug, tsis muaj zog, lossis txo qis - kawg torque.

Lub tshuab nqus dej siab rov qab ntws (cc/min) lossis asymmetrical flow-muab rau ntawm qhov ntsuas lub rooj zaum.

Pom pom bore hnav ntawm teardown tab sis tseem nyob hauv qhov txwv tsis pub siv.

Yog tias qhov kev kuaj xyuas tawm, IW5 feem ntau yog qhov kev kho kom zoo tshaj plaws.





CovIW 5 plungeryog ib qho me me, qhov tseeb uas nws qhov tseeb ncaj qha cuam tshuam rau lub twj tso kua mis metering, combustion quality thiab fleet nqi. Thaum tau txais los ntawm cov neeg xa khoom muaj npe nrov thiab tau teeb tsa nrog kev tshuaj xyuas nruj nruj, cov khoom sib dhos- tswj kev sib dhos, sib tw txoj kab uas hla pawg thiab yuav tsum tau siv lub rooj ntev zaum, IW5 cov khoom hloov rov qab nyob ze -OEM kev ua tau zoo ntawm ib feem ntawm tag nrho- cov nqi hloov twj tso kua mis - ua rau lawv qhov kev xaiv tsis tseem ceeb rau kev ua haujlwm thiab kev saib xyuas kev ua haujlwm. cov kev pab cuam.





Txhawm rau ua kom koj qhov kev yuav khoom tau yooj yim thiab yooj yim, peb muab ntau yam kev xaiv them nyiaj ruaj ntseg:

Peb nyob ntawm no los ua kom koj cov txheej txheem xaj kev txhawj xeeb-dawb - xaiv txoj kev them nyiaj uas ua haujlwm zoo tshaj rau koj!





Cim npe nrov: iw5 plunger — precision twj tso kua mis caij rau siab -kev ua tau zoo diesel systems, Tuam Tshoj iw5 plunger — precision twj tso kua mis caij rau siab -kev ua tau zoo diesel systems manufacturers, lwm tus neeg, Hoobkas
